GEANT GN-CX 300 MINI HYBRID RECEIVER LATEST SOFTWARE
GEANT GN-CX 300 MINI HYBRID Satellite Receiver Software Latest Update. Update Geant HD Receiver Firmware with New Option. For All Model Geant HD Receiver, Latest Software Update Click Here. New Updates and For any Help Contact Us on Facebook Page or Twitter.
Subscription :
IPTV : 12 mois APPOLO
Server : 15 mois Forever_IKS_126
SPECIFICATION :
Processor and Memory Chipset GX6621
CPU 32-bit CK610M, Up to 600MHz
GPU multi-standard video decoder
Flash 8MByte(SPI Nor Flash)
SDRAM 2Gbit DDR3
Interfaces LNB DVB-S2 Tuner In (Tuner IC:RDA5815M)
1 AV 4bit connector Audio/CVBS/Coaxial
1 HDMI HD output connector “HDMI output with upscale supporting up
to 480p&480i,576p & 576i, 720p&1080i50Hz&1080P50Hz;HDMI 1.4 supports HDCP 1.2 and DDC”
1 RJ45 ethernet Interface without LED
2 USB 2.0 “1 USB On Rear, 1 USB On Front ;Support USB WIFI/3G device”
1 smart card interface Support 5V CA card
General Features
Operation System ECOS
Power consumption “Working power consumption ?Less than 12W;”
Etehernet
10/100 MBit compatible Ethernet Interface
Play video files connect Youtube website and some other video website
G-MSCREEN
G-NET-UPDATE?GVOD?GIPTV
Internet Radio IPTV protocol[http or rtsp,rtmp,mms]
sat2ip?rss
Storage
“USB2.0,High-speed and Full-speed devices supported, PVR is supported”
supported all kind of storage ,recording,playing and connecting all kind of USB equipment.
Format: PAL, NTSC,SECAM
Video Full Resolution:1920 ž 1080P 1920 ž 1080i and 1280 ž 720p for HD video,720 ž 480p, 720 ž 480i, 720 ž 576i, and 720 ž 576p for SD video
“Standard: HEVC/H.265,ISO/IEC 14496-10,ISO/IEC 14496-2,ISO/IEC 13818-2,ISO/IEC 11172-2
H 265 video,BP/MP/HP up to L4.1,H.264 video,SP/ASP up to L5,MPEG-4 video,
H.263 P3,AVS,AVS plus,MPEG-2 video,MP@HL,MPEG-1 video”
Aspect Ratio: 4:3, 16:9 Pan & Scan, Letterbox
True full Color(32 bits)on screen display (OSD),QT osd supported
Video planes: 6 panes (2 graphic planes, 2 display planes, background, cursor)
Audio
“Standard: ISO/IEC 13818-3
Decoding: MPEG1 I/II, MP3,MPEG-4 AAC and AAC plus (HE-AACv1 and v2),DRA,Dolby Digital (AC-3),
Dolby Digital Plus (DD+)”
“Sampling Frequency :32, 44.1, 48KHz,and MPEG-2 half sampling rates of 16kHz,22.05kHz, 24kHz
Audio Output Impedance: Low”
Output Mode: Single channel, Dual-channel, Stereo, Left, and Right.
Standard? JPG,BMP,GIF,PNG
DVB Function Storing memory:4000 TP , 8000 channels
network search, auto search and TP search
Supported programme lock,delete,move(group move),rename,swap
favorite group and parental lock supported
Supported transponder add ,delete,edit
Supported multi-language menue(English. Franch.Russia.Greek.Italian.Arabic.Farsi,Ukrain,Swedish,
Spanish,Turkish,German etc)
PIP supproted(support 9 SD channels or 2 HD channels)
Easy functions such as Group Move/Recall History
“7 days Electronic Program Guide (EPG)[can up to 14 days ],epg from internet
Teletext output through VBI and OSD”
Software(data,kernel and file system) upgrade through USB or Ethernet
Multi-language DVB Subtitle output
Tuner & Channel
DVB-S/ S2 DVB-S / DVB-S2 Satellite Compliant (MPEG-I/MPEG-II/ MPEG-IV/ H.263/H.264/H.265)
Input impedance 75?
input frequency 950~2150MHz
Symbol rate 2.0~45 MS/s
Tuner RDA5815M
Demodulation QPSK.8PSK,16APSK,32APSK
Device Parameter
Power dissipation Max 30W
Input voltage ? AC 100-240V~
Working Temperature 0 ? 40?
Size 280mm
IPTV : 12 mois APPOLO
Server : 15 mois Forever_IKS_126
GN-CX 300 MINI HYBRID Files
