GTMedia V8 Finder BT03 DVB-S2 Satellite Signal Finder Box BT Connect Via Phonee APP SOFTWARE UPDATE DOWNLOAD
GTMEDIA V8 FINDER BT03 Software Latest Update. Download GTMedia Satellite Receiver Manual, and Software with New Option. For All Model GTMedia Receiver Update Click Here. Icone Receiver Software, For any Help Contact Us @ Facebook Page or Twitter.
About this item
DVB Finder DVB-S2 Multi standard demodulation & decoding
Bluetooth connection for Android APP and Apple APP
Support full satellite selection. Support 1 to 60Mbaud symbol rates. VCM mode supported, Dummy frame insertion supported, Automatic standard recognition
Multi standard demodulation & decoding DVB-S2 CCM,QPSK
Â
Product description :
Specification:
Product Size: 42*95*15 MM
Gift Box size: 118*80*35MM
Weight (1set): 0.12 Kg (G.W.)
LED display Color: Blue
Output Interface: LNB IN*1,MINI USB 5V IN*1
Accessories: DVB Finder BOX*1, MINI USB cable*1
System introduction
Multi standard demodulation & decoding
DVB-S2 CCM,QPSK+1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
8PSK+3/5, 2/3, 3/4, 5/6, 8/9, 9/10 16APSK+2/3, 3/4, 4/5, 5/6, 8/9, 9/10
32APSK+3/4, 4/5, 5/6, 8/9, 9/10
Legacy DVB-S,QPSK+1/2, 2/3, 3/4, 5/6, 7/8
VCM mode supported
Dummy frame insertion supported
Automatic standard recognition
Support 1 to 60Mbaud symbol rates
Fast channel blind scan for RF frequency & symbol rate acquisition
High performance equalizer, canceling echo introduced by front end
Simple AGC – Tuner interface
Build in DC cancellers to remove DC component
IQ imbalance compensator
Automatic roll-off factor (0.35/0.25/0.20) detection
Automatic spectrum inversion
Signal quality and statistic, allowing improved monitoring and debug
DiSEqCTM v2.2 modulation output for full control of LNB and satellite antenna
Â
Important Note: 1- backup the channel list.                    Backup Channel List 2- export the softcam.key to usb device             Backup softcam.key 3- update the firmware to box by allcode mode 4- update channel list then import softcam.key
Download Gtmedia Tools
How to Update Gtmedia Receiver
How To Dump Flash Gtmedia
File Name
New! GTMEDIA V8 Finder BT03_ V22.8.6 27102021.rar
change log:
1. Add system Turkish translation;
2. Add FEC and modulation method and other information display;
3. Modify the more intuitive and convenient finder panel UI;
4. Increase the satellite list search function;
GTMedia V8 Finder BT03 Satellite Signal Finder Software 27/10/2021
DOWNLOAD GTMedia V8 Finder BT03 DVB-S2 Satellite Signal Finder SOFTWARE NEW UPDATE
